9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
Term (Terminal Block) - 10A Fuse
WIRE COLOR FUNCTION
Red / Dark Green Power from Chassis
Splice
Orange / White Power to Key Acc Splice
Accessory - 10A Fuse
WIRE COLOR FUNCTION
Red
Power from Solenoid B+
Orange / White Power to 12V Receptacle
Drive - 10A Fuse
WIRE COLOR FUNCTION
Red / Dark Green Power from Chassis
Splice
Red / Dark Green Power to AWD Coil
Lights - 15A Fuse
WIRE COLOR FUNCTION
Red / Dark Green Power from Chassis
Splice
Red / Yellow Power to Lights B+ Splice
EPAS - 20A Fuse
WIRE COLOR FUNCTION
Red
Power from Solenoid B+
Red
Power to EPS Relay high
side
FUSE / CIRCUIT BREAKER CIRCUITS (2019)
EPS 25A
WIRE COLOR FUNCTION
RD
EPS B+, Fuse In
RD Unswitched Fused B+,
EPS Fuse Out
EFI 10A
WIRE COLOR FUNCTION
RD EFI B+, Fuse In
RD
Unswitched fused B+, EFI
Relay In
Lights 15A
WIRE COLOR FUNCTION
RD/DG Chassis Relay Out, Lights
Input
RD/YE
Lights B+, Lights Fuse
Out
Key 10A
WIRE COLOR FUNCTION
RD Key B+, Fuse In
RD/WH
Unswitched Fused B+,
Key Fuse Out
Drive 10A
WIRE COLOR FUNCTION
RD/DG Switched B+, Drive Fuse
Out
RD/DG Chassis Relay, Drive
Input
TERM 10A
WIRE COLOR FUNCTION
OG/WH
Accessory Terminal, Fuse
Out
RD/DG
Accessory Terminal, Fuse
In
Accessory 10A
ELECTRICAL
