5. Place a suitable stand under the footrest frame to raise the wheel slightly off
the ground.
6. Remove the wheel nuts. Remove the wheel.
WHEEL INSTALLATION
1. Place the wheel on the wheel hub with the valve stem toward the outside and
the rotation arrows on the tire pointing toward forward rotation.
2. Install the wheel nuts finger tight.
3. Lower the vehicle to the ground.
4. Torque the wheel nuts to specification.
WARNING
Loose nuts could cause a tire to come off during operation, which could result
in an accident or rollover. Always ensure that all nuts are torqued to
specification.
WHEEL NUT TORQUE SPECIFICATIONS
Check the wheel nut torques occasionally and when they’ve been loosened for
service
Location
Nut Torque
Front Wheel
27 ft. lbs. (37 Nm)
Rear Wheel
27 ft. lbs. (37 Nm)
AIR FILTER
1. Position the vehicle on a level surface.
2. Place the transmission in gear.
3. Lock the parking brake.
4. Remove the seat.
65
MAINTENANCE
