Polaris RANGER XP 1000 2018 - Sae;Metric Tap;Drill Sizes; Sae Tap; Drill Sizes

9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
1.23
SAE TAP / DRILL SIZES
THREAD
SIZE DRILL SIZE
THREAD
SIZE DRILL SIZE
#0–80 3/64 1/2–13 27/64
#1–64
53
1/2–20 29/64
#1–72 53 9/16–12 31/64
#2–56 51 9/16–18 33/64
#2–64 50 5/8–11 17/32
#3–48 5/64 5/8–18 37/64
#3–56
45
3/4–10 21/32
#4–40
43
3/4–16 11/16
#4–48
42
7/8–9 49/64
#5–40
38
7/8–14 13/16
#5–44 37 1–8 7/8
#6–32 36 1–12 59/64
#6–40
33
1 1/8–7 63/64
#8–32
29
1 1/8–12 1 3/64
#8–36
29
1 1/4–7 1 7/64
#10–24
24
1 1/4–12 1 11/64
#10–32
21
1 1/2–6 1 11/32
#12–24 17 1 1/2–12 1 27/64
#12–28 4.6 mm 1 3/4–5 1 9/16
1/4–20
7
1 3/4–12 1 43/64
1/4–28
3
2–4 1/2 1 25/32
5/16–18
F 2–12
1 59/64
5/16–24
I
2 1/4–4 1/2 2 1/32
3/8–16 O 2 1/2–4 2 1/4
3/8–24 Q 2 3/4–4 2 1/2
7/16–14
U 3–4
2 3/4
7/16–20 25/64
METRIC TAP / DRILL SIZES
TAP SIZE DRILL SIZE DECIMAL
NEAREST
FRACTION
3 x .50
#39
0.0995
3/32
3 x .60
3/32
0.0937
3/32
4 x .70
#30
0.1285
1/8
4 x .75
1/8 0.125 1/8
5 x .80 #19 0.166 11/64
5 x .90
#20
0.161
5/32
6 x 1.00
#9
0.196
13/64
7 x 1.00
16/64
0.234
15/64
8 x 1.00 J 0.277
9/32
8 x 1.25
17/64
0.265
17/64
9 x 1.00 5/16 0.3125 5/16
9 x 1.25
5/16
0.3125
5/16
10 x 1.25
11/32
0.3437
11/32
10 x 1.50 R 0.339
11/32
11 x 1.50
3/8
0.375
3/8
12 x 1.50
13/32
0.406
13/32
12 x 1.75 13/32 0.406 13/32
GENERAL INFORMATION
1
