BRAKE SYSTEM - HYDRAULIC COMPONENTS
Banjo Bolts (All):
14.5 ft. lbs. (19.6 Nm).
Bleed Screws (All):
47 in. lbs. (5.3 Nm)
Master Cylinder
LH Front Caliper
2
RH Front Caliper
1
1
2
Caliper Mounting Bolts (All):
3
18.0 ft. lbs. (24.5 Nm).
Brake Pad Guide Pins:
4
12.0 ft. lbs. (16.2 Nm).
4
3
2
3
1
60 in-lbs. (6.8 Nm)
Adaptor Clamps
2
17.0 ft-lbs.
(23.0 Nm)
60 in-lbs.
(6.8 Nm)
15 in-lbs.
(1.7 Nm)
1
Rear Caliper
3
4
1 (All Banjo Bolts)
52 in-lbs.
(5.8 Nm)
60 in-lbs.
(6.8 Nm)
4
