ELECTRICAL COMPONENT LOCATIONS (FRONT)
3!
Headlight Switch
4)
Start Command Load Plug
4(
EPS Signal
3@
AWD Switch
4!
Chassis Ground
5)
Cooling Fan
3#
C4 Gauge
4@
Audio Amplifier
5!
Left Headlight
3$
Key Switch
4#
Right Tweeter
5@
Right Headlight
3%
Diagnostic Plug
4$
Rear Audio
5#
Ambient Air Temperature Sensor
3^
Ride Command Display
4%
Left Tweeter
5$
Front Accent Light
3&
LED Dash Light
4^
AWD Coil
5%
GPS Antenna
3*
Accent Light
4&
Antenna Harness
5^
Voltage Regulator
3(
SCM
4*
EPS Power
5&
Shock Actuator
