Sportsman Transmission Exploded View (4X4),
Continued
REF.
QTY.
DESCRIPTION REF.
QTY.
DESCRIPTION
1. 20 Screw 45. 1 Shift Drum
2. 2
Triple Lip Seal
46. 1
Sector Gear, 31 T
3. 1 LH Gearcase 47. 1 Shift Shaft
4. 2
Ball Bearing
48. 1
O-Ring
5. 1 Silent Chain 49. 1 Detent Pawl
6. 1 RH Gearcase 50. 1
Compression Spring
7. 2
Ball Bearing
51. 1 Sector Gear Cover
8. 1
Sprocket, 19 T
52. 1 Bellcrank
9. 1 Oil Deflector 53. 1 Lock Nut
10. 2 Screw 54. 1 Shift Switch
11. 1
Output Gear, 91 T
55. 1
Retaining Ring
12. 1
Retaining Ring
56. 1
Sector Gear, 16 T
13. 9 Screw 57. 1 Detent Star
14. 1
Bearing Cover
58. 1
O-Ring
15. 2
Retaining Ring
59. 1 Snorkel Shaft
16. 1 Shim 60. 1
Ball Bearing
17. 1
Ball Bearing
61. 1
Retaining Ring
18. 1 Center Drive Shaft 62. 1 Snorkel Tube
19. 1
Retaining Ring
63. 5 Screw
20. 1 Thrust Washer 64. 1 Shim
21. 1
Gear, 32 T
65. 1
Retaining Ring
22. 1
Needle Bearing
66. 1
Triple Lip Seal
23. 1 Washer 67. 1 Vent Tube
24 1
Engagement Dog
69. 2 Dowel Pin
25. 1
Engagement Dog
70. 1
Plug
26. 2
Retaining Ring
71. 2
Compression Spring
27. 2 Washer 72. 2
Retaining Ring
28. 1
Sprocket, 38 T
73. 2
Cup Washer
29. 1
Reverse Shaft, 26 T
74. 1
Retaining Ring
30. 1
Gear, 33 T
75. 1 Shim
31. 1 Shift Collar 76. 1
Needle Bearing
32. 1 Park Plate 77. 1
Speed Sensor
33. 2
Ball Bearing
78. 1
O-Ring
34. 1 Seal 79. 1
Output Shaft
35. 2
Ball Bearing
84. 1 Lockout Disc
36. 1
Input Shaft
85. 1
Magnetic Plug
37. 1 Chain
38. 2 Shift Fork
39. 2
Compression Spring
40. 1 Shift Rail
41. 1 Tensioner Pin
42. 1
Torsion Spring
43. 1 Chain Tensioner Cam
44. 1 Chain Tensioner Shoe
TRANSMISSION
