14
Composite Video Connection
If your external device has composite jacks/sockets, connect them to the television using a composite
video/audio cable. There are two ways of doing this dependent on your model.
RCA (phono) Cables
Video / Y
Pb
Pr
R
L
R
L
Video CVBS
(A)
(B)
Mini AV Source
(A)
(B)(C)
(A)
(B)
(C)
External Device
Composite video/audio adapter cable (not supplied)
(A)
(B)
External Device
Composite video/audio cable (not supplied)
Composite video/audio cable (not supplied)
R
L
Video CVBS
Getting Started
AV in
