Polaroid TLM-23201B User Manual

32″LCD TV Polaroid TLM-23201B
52
CN902 033T327812D WAFER 12P PLUG
CN903 033T380213B Y CONNECTOR
IC932 056G 139 3B IC PC123Y82FZ0F
IC952 056G 139 3B IC PC123Y82FZ0F
IC934 056G 139 3B IC PC123Y82FZ0F
Q932 057G 761 7 KTD1691P
R915 061T153M10852T RST MOFR 0.1 OHM +-5% 3WS
C901 063G107K474 US 0.47UF +-10%
C904 063G107K474 US 0.47UF +-10%
C905 063G210K105BCN MPP CAP 1uF 520V P=15mm
C941 063G211J273 5C 10 0.027uF 5% 1000V P=15mm
C951 065G 1K103 2E6921 CAP CER 10NF K 1KV Y5P
C952 065G 1K103 2E6921 CAP CER 10NF K 1KV Y5P
C906 065G306M1022BM GP Y1.CAP.001UF 250VAC MURATA
C950 065G306M1022BM GP Y1.CAP.001UF 250VAC MURATA
C903 065G306M1022BM GP Y1.CAP.001UF 250VAC MURATA
C902 065G306M1022BM GP Y1.CAP.001UF 250VAC MURATA
C926 067G215A1024KV EC 1000uF 25V 12.5*20mm
C943 067G215A1026KV EC 1000uF 35V 12.5*25mm
C928 067G215A4713KV EC 470uF 16V M 10*12mm
C944 067G215A4716KV EC 470uF 35V M 10*16mm
C946 067G215S4714KL
LOW ESR EC 470UF 25V BY 金山
L903 071G 55 21 FERRITE BEAD
FB906 071T 55 26 S FERRITE CORE
FB901 071T 55 26 S FERRITE CORE
L932 073G 253 91 H CHOKE COIL
L931 073G 253 91 H CHOKE COIL
L971 073G 253150 L CHOCK
L901 073T 174106 V LINE FILTER 13mH MIN
L902 073T 174106 V LINE FILTER 13mH MIN
L906 073T 174122 L PFC CHOKE 230uH PT-009321
T931 080TL32T 5 N X'FMR 1.9mH YUVA-827
T951 080TL40T 8 YS X'FMR 600uH YS04160149
CN901 087T 501 44 DL AC SOCKET 3PIN + 2 SCREW Hole V/T
705TQ757011 Q951 ASS'Y
Q951 057G 611 9 FET 2SK4097LS 9.5A/500V TO-220FI(LS)
0M1G1730 8120 SCREW
Q90G6084 3 heat sink
705TQ757012 Q952 ASS'Y
Q952 057G 611 9 FET 2SK4097LS 9.5A/500V TO-220FI(LS)
0M1G1730 8120 SCREW
Q90G6084 3 heat sink
705TQ757013 Q931 ASS'Y
Q931 057G 667 52 FET 2SK4100LS-T 7A/650V TO-220FI(LS)
0M1G1730 8120 SCREW
Q90G6084 3 heat sink
705TQ757022 Q901 ASS'Y
Q901 057G 600 72 FET SPW16N50C3 16A/560V P-TO247
0M1G1730 10120 SCREW 42A9930016
Q12G 372 8 SILICON
Q90T0095 2 HEAT SINK
