●EX. The ignition signal setting is changed
from 1 to 2 (4C-4P).
●Press down the button for 3 seconds, to back
the RPM screen.
The button function instruction
4
RPM pulse setting
5
●The RPM screen。
Press the button one time to
switch between the RPM screen
and the MAX RPM record screen.
●Hold pressing the button for 3 seconds to
reset the Max. RPM record.
Now the RPM pulse setting is flashing!
Most of the 4 strokes bikes with single cylinder are
igniting every 360 degree once, so the setting should be the same
as the bike with 2-cycle and one piston engine.
The setting
value
0.5
1 2C-1P
4C-1P
4C-2P
4C-3P
4C-4P
4C-5P
4C-6P
4C-8P
4C-10P
4C-12P
2C-2P
2C-3P
2C-4P
2C-6P
1.5
2
2.5
3
4
5
6
The corresponding
stroke and pistons number.
The corresponding RPM signal number per ignition.
2 RPM signals per 1 ignition.
1 RPM signal per 1 ignition.
2 RPM signals per 3 ignition.
1 RPM signal per 2 ignition.
2 RPM signals per 4 ignition.
1 RPM signal per 3 ignition.
1 RPM signal per 4 ignition.
1 RPM signal per 5 ignition.
1 RPM signal per 6 ignition.
6
34.4
17.2
69.8
-10~60℃
JIS D 0203
●
Effective temperature range
●Battery type
●
Meter weight
●Meter size
●Meter standard
Design and specifications are subject to change without notice!
The meter will turn off automatically if you don't press the button and there is no signal input for 30 seconds.
The following situation do not indicate malfunction of the meter.Please check the following before taking it in for repair.
The meter shows wrong
information.
●Maybe the problem is caused by the
insufficient power
→Please change the inner battery.
(CR 2032.)
●Maybe the problem is
caused by wrong
battery installation
→Please check is the battery direction is
correct.
Trouble Check item
Tachometer does not
appear or appear
incorrectly.
●Please check the RPM sensor wiring is
connected correctly.
●Please check the spark plug is R type
or not. If not, please replace the spark
plug with the R type spark plug.
●Please check your setting.
→Please refer to the manual 5.
Trouble Check item
●Battery life time About 350 H (when battery volume below 250 mAh)
About 47.6g
3
CR 2032
●Supply voltage DC 12V
W69.8 X L34.4 X H17.2 mm
The turn on the meter- The meter will
turn on auto-matically when you press the button or there
is a signal input.
The main screen-The meter will turn off automatically if you
don't press the button and there is no signal input for 30 seconds.
CAUTION!
Instruction of function
Trouble shooting
Display range：0~15,000 RPM
●Digital Tachometer
Display unit：10 RPM
<0.5
Sec.
○Display internal
Display range: 0~15,000 RPM
○MAX RPM record
Setting range
：0.5, 1, 1.5, 2, 2.5, 3, 4, 5, 6
○RPM input pulse
●In RPM screen, hold pressing down the button
for 3 seconds to enter the RPM pulse setting.
The piston type can be set is ：
0.5,1,1.5,2,2.5,3,4,5,6。
●EX. You want to change the current setting
value from 1 to 2.
●In setting screen, press the button one time to
ching the RPM pulse setting value.
●EX. The original setting is 0.5 (4C-1P).
CAUTION!CAUTION!
(
RPM screen
)
(MAX RPM record screen
)
※If the problem couldn't be solved after above checking, please contact the local dealer.
