Additional lights installation
The motor body is equipped with a plastic block for
the light wiring that must have the following features:
1. Lights voltage: 6 Vdc
2. The sum of the lights powers must not exceed 8W
3. The block is provided with 2 cables fixing points,
+ (pink) and – (black) .
Connect the + of the motor to the + of the front
and rear lights.
Connect the - of the motor to the - of the front and
rear lights.
4. To proceed with this connection, insert the 3+3
cables between the two small metallic plates
placed on the plastic block and tight them using
the proper screws
Installation of
additional headlights
