GP 44
Spare Parts - 11 -
PART LIST POOL BOX FIG. A-7-3-H
Key Part-No Description Key Part-No Description Key Part-No Description
1 P30221 Pool Box 31 4 M09090 Rail 5mm Strap
2 B04120 Cap Screw M4×20 32 4 M09328 Rail 6mm Strap
3 M09100 Rail Cover 33 4 M09329 Rail 7mm Strap
4
34 4 M09330 Rail 9.5mm Strap
5 P06056 Rail Bracket 35 4 M09331 Rail 12mm Strap
6 B27100 Spring Washer M4 36 4 M09336 Rail 14mm Strap
7 B17100 Nut M4 37 4 M09332 Rail 15mm Strap
8 B27200 Spring Washer M5 38
9 B04210 Cap Screw M5×10 39 22 L21029 Knob Nut 5mm Strap
10 NEWS-409 Left Bracket for Rail 40 22 L21030 Knob Nut 6mm Strap
11 P30222 Pool Box Cover 41 22 L21031 Knob Nut 7mm Strap
12 B17300 Nut M6 42 22 L21032 Knob Nut 8mm Strap
13 B08110 Hexagon Bolt M4×10 43 22 L21033 Knob Nut 9.5mm Strap
14 B26100 Flat Washer M4 44 22 L21034 Knob Nut 12mm Strap
15 B27000 Spring Washer M3 45 22 L21054 Knob Nut 14mm Strap
16 B17000 Nut M3 46 22 L21035 Knob Nut 15mm Strap
17 P39001 Hinge 47
18 B02010 Flat Head Bolt M3×10 48
19 B12315 Eye Bolt M6×15 49
20 B27300 Spring Washer M6 50
21 B26300 Flat Washer M6 51
22
52
23 N00037 Pool Door 53
24 B00008 Pan Head Screw M3×8 54
25 55
26 56
27 57
28 58
29 59
30 60 Drawing FIG. A-7-3-D
