GP 44
Spare Parts - 13 -
The different parts for strap size and the arch size.
Key Part-No Description Key Part-No Description Key Part-No Description
1 P30221 Pool Box 31 B27100 Spring Washer M4 3 L00044 Spacer 5mm Strap
2 B04330 Cap Screw M6×30 32 B17100 Nut M4 3 L00045 Spacer 6mm Strap
3 * * 33 B04112 Cap Screw M4×12 3 L00035 Spacer 7mm Strap
4 B04320 Cap Screw M6×20 34 NEWS-251 Circuit Protector Base 3 L00046 Spacer 8mm Strap
5 B27300 Spring Washer M6 35 E09034 Fuse Holder F-120B 3 L00047 Spacer 9.5mm Strap
6 B17300 Nut M6 36 E09071 Fuse MDA-10 3 L00048 Spacer 12mm Strap
7 B04315 Cap Screw M6×15 37 E09048 Fuse MF65-ACD10A 3 L00104 Spacer 14mm Strap
8 P18060 Shim 38 B00110 Pan Head Screw M4×10 3 L00049 Spacer 15mm Strap
9 L00053 Collar 39
10 T04043 Ball Bearing 6001LLU 40
11 P33015 Bearing Stopper 41
12 M06010 Key 5×5×25 42
13 E21035 M5 Motor (Strap Loading) 2ph 80W 43
14 L00051 Collar 44
15 B05540 Cap Screw M10×40 45
16 B26500 Flat Washer M10 46
17 B04330 Cap Screw M6×30 47
18 B06330 Flat Head Screw M6×30 48
19 L03051 Chamber Feed Roller 49
20 B10208 Set Bolt M5×8 50
21 T04031 Ball Bearing 6002LLU 51
22 N01065 Rubber Roller 52
23 B30032 C Ring R-32 53
24 P18057 Shim 54
25 P18058 Shim 55
26 L00040 Rubber Roller Collar 56
27 B27500 Spring Washer M10 57
28 B17500 Nut M10 58
29 P18061 Shim 59
30 P03177 Detect Lever Guide 60 Drawing FIG. A-7-64-D
PART LIST POOL BOX FIG. A-7-64-D
PART LIST POOL BOX FIG. A-7-64-H
