GP 44
Spare Parts - 37 -
PART LIST
PIVOT ROLLER UNIT FIG. HEAD-2P
Key Part-No Description Key Part-No Description
1 P03113 Snap Ring E-6 9 B27200 Spring Washer M5
2 B26400 Flat Washer M8 10 B04210 Cap Screw M5×10
3 T05001 Needle Bearing TLA810 11 * *
4 L09034 Feed Roller Long Pin 12 * *
5 C03044 Strap Feed Arm 13 * *
6 L00061 Collar 14 * *
7 T04033 Ball Bearing 628LLB 15 * *
8 B26200 Flat Washer M5 16 * *
To Next Page
