AssemblyInstructions‐PSM‐100(Revised11/2009)

NOTINTENDEDFORCHILDRENAGE12ANDUNDER
2

STEP1:DECALPLACEMENT(SEEPICTUREONPAGEONEFORPLACEMENT)
 HARDWARENEEDED:
 1/2”X50”ORANGETAPEDECAL
 BLUE“POOL”DECAL
 ORANGE“SHOT”DECAL

 LOCATE1/2”X50”ORANGETAPEDECAL,LAYBACKBOARDONTHEGROUNDFRONTFACINGUP.LOCATEDIN
THECENTEROFTHEBACKBOARDISTHEMOLDEDINSQUARE,THISSQUAREHASADIFFERENTTEXTURETHENTHEREST
OFTHEBACKBOARD.PLACETHEENDOFTHEORANGETAPEINONECORNEROF
THESQUARE,MEASURETHELENGTH
OFONESIDEOFTHESQUAREWITHTAPE,CUTTAPETOLENGTH.PEELOFFBACKOFTHETAPEANDCAREFULLYPLACE
TAPESTICKYSIDEDOWNONSIDEOFTHESQUAREYOUJUSTMEASURED.REPEATFORTHEREMAININGTHREESIDESOF
THESQUARE.
 LOCATETHEBLUE
“POOL”DECAL,LAYBASEONITSBACKWITHTHEFRONTOFTHEBASEFACINGUP.PLACETHE
“POOL”DECALINTHECENTERTOPTOBOTTONOFTHELEFTSIDEOFTHEMIDDLEPORTIONOFTHEFRONTOFTHEBASE.
 LOCATETHEORANGE“SHOT”DECALPLACETHE“SHOT”DECALINTHECENTER
OFTHERIGHTSIDEOFTHE
MIDDLEPORTIONONTHEFRONTOFTHEBASE.
 NOTE:IFYOUAREHAVINGTROUBLEGETTINGTHEDECALSTOSTICKTOTHEPLASTIC,CLEANTHESURFACEBY
USINGALCOHOLTOCLEANTHEAREA.WHENTHEAREAISDRYTRYAPPLYINGTHEDECALSAGAIN.

STEP2:INSERTBOATPLUG
HARDWARENEEDED:
 1‐BOATPLUG

 TAKETHEBRASS/RUBBERBOATPLUGANDFULLYINSERTITINTOTHERECESSEDDRAINHOLELOCATEDATTHE
BACKENDOFTHEBASENEARITSBOTTOM.BEGINTURNINGTHEBRASS“T”INACLOCKWISEDIRECTIONWHILE
PUSHINGTHEPLUGINTOTHEDRAINHOLE.THEPLUGSHOULDBEGINTOEXPANDWITHINTHE
DRAINHOLE.TIGHTEN
ENOUGHTOASSUREAWATERTIGHTFITBUTDONOTOVERTIGHTENPLUG.YOUMAYNEEDTOUSEPLIERSTOTIGHTEN
ENOUGHFORAGOODWATERTIGHTSEAL.
NOTE:IFTHEPLUGSIZEAPPEARSTOBETOOSMALLBEFORETIGHTENING,HOLDTHERUBBERPARTIN
 ONEHANDANDTURN
THEBRASS“T”INACLOCKWISEDIRECTIONWITHYOUROTHERHAND.
 THEPLUGSHOULDBEGINEXPANDINGINYOURHAND.ALLOWTHEPLUGTOEXPNADALITTLE
 ANDTHENRE‐INSERTITINTOTHEBASEDRAINHOLEANDFOLLOWTHEPROCEDURE
 AGAIN.

STEP3:CONNECTINGBASEANDBACKBOARD
CAREFULLYPICKUPTHEBACKBOARDWITHTHEORANGESQUARETARGETFACINGYOUANDSLIDEITSBOTTOM
SECTIONINTOTHETOPSECTIONOFTHEBASEFROMTHEFRONTOFTHEBASEUNITLTHEBACKBOARDCOMESTOA
STOP.BESURETHE“POOLSHOT”DECALISFACINGYOUWHENYOUSLIDETHEBACKBOARD
INTOTHEBASE.







