AssemblyInstructions‐PSM‐100(Revised11/2009)



NOTINTENDEDFORCHILDRENAGE12ANDUNDER

4



STEP5:

ATTACHINGTHE15”RIM

HARDWARENEEDED:

1‐15”RIM

4‐5/16”X2‐1/2”BOLTS

4‐5/16”LOCKNUTS

8‐5/16”FLATWASHERS

1‐BASKETBALLNET



 SLIPA5/16”FLATWASHEROVERONEOFTHE5/16”X2‐1/2”BOLTS.INSERTTHISBOLTTHROUGHONEOFTHE

HOLESONTHE15”RIMFROMTHEFRONTOFTHERIMANDTHENTHROUGHTHECORRESPONDINGHOLEINTHE

BACKBOARD.PLACEANOTHER5/16”FLATWASHEROVERTHEPORTIONOF

THEBOLTNOWSTICKINGOUTTHROUGH

THEBACKOFTHEBACKBOARDANDHANDTIGHTENWITHA5/16”NYLONLOCKNUT.REPEATFORTHEREMAINING

BOLTSTOCONNECTTHERIMTOTHEBACKBOARD.NOWSECUREALLFOURBOLTSWITHYOUR9/16”WRENCHINTHE

FRONTANDTHE1/2”RATCHETINTHEBACK.

DONOTOVER‐TIGHTENTHEFOURBOLTSONLYTIGHTENTOASNUGFIT

ORBACKBOARDWILLWARP.



NOWATTACHTHENETTOTHEHOOPBYLOOPINGITTHROUGHTHENETRETAINERSON THEHOOP.



NOTE:IFANYOFTHEHOLESINTHEBACKBOARDAPPEARTOBETOOSMALLFORTHEBOLTS,PRESSASCREW

DRIVER

THROUGHTHEHOLEANDROTATESEVERALTIMESTOENLARGEHOLE.



STEP6:FILLINGTHEBASE WITHSANDORWATER

HARDWARENEEDED:

 1‐ORANGEPLUG



 PLACETHEFULLYASSEMBLEDUNITAPPROXIMATELY3TO6NCHESFROMTHEEDGEOFTHESWIMMINGPOOL.

BESURETHEHOOPISFACINGTHEPOOLANDTHEBASEISPARALLELTOTHEPOOLEDGE.MAKESUREBASEISNOT

OVERHANGINGTHEPOOLEDGEANDISCOMPLETELYFLATONTHEPOOL

DECK.



IFUSINGWATERASWEIGHT:

BEFORECOMPLETELYFILLINGWITHWATER,WERECOMMENDTHATYOUPOUR

APPROXIMATELYONE(1)QUARTOFLIQUIDBLEACHORCHLORINEINTOTHEBASETOHELPPREVENTALGAEGROWTH.

(NOTAPPLICABLEWHENUSINGSAND)TAKETHEGARDENHOSEANDPLACEITSENDINTOTHEFILLHOLELOCATEDAT

THETOPOFBASE.

TURNONTHEWATERANDCOMPLETELYFILLTHEBASETOTHETOPOFTHEFILLHOLE.



IFUSINGSANDASWEIGHT:

WITHAFUNNEL,FILLTHEBASEWITHADDITIONALSANDTHROUGHTHEFILLHOLE

LOCATEDATTHETOPOFBASE.FILLTHEBASETOABOUT1/2TO2/3OFITSFULLCAPACITYWITHSAND.



NOWLOCATETHEORANGEPLUGANDINSERTITINTOTHEBASEFILLHOLEBYPRESSINGITDOWNFIRMLYUNTILITIS

FULLYSEATEDINPLACE.



CONGRATULATIONS!!!....YOURASSEMBLYISCOMPLETE.



BEFOREANYUSE,PLEASEREADALLTHEFOLLOWINGSAFETYINFORMATIONFORTHISPRODUCT.


