MPK with CommandPak

™

Control System BACnet /IP User’s Guide

OBJECT

TYPE

READ/

WRITE

OBJECT

INSTANCE

OBJECT NAME DESCRIPTION UNITS

AV R 1003 CPR2_xwiActiveFaultCode Cmpr2 Fault Code See below

AV R 1004 CPR2_xwiMode Cmpr2 Actual Mode See below

AV R 1005 CPR3_xwiActiveFaultCode Cmpr3 Fault Code See below

AV R 1006 CPR3_xwiMode Cmpr3 Actual Mode See below

AV W 1007 twiSetInpEvtMinMixBoxPos Event Min Mix Box Pos Setpoint %

AV W 1008 twiSetInpMaxMixBoxPos Max Mix Box Pos Setpoint %

AV W 1009 twiSetInpMinMixBoxPos Min Mix Box Pos Setpoint %

AV W 1010 twiSetInpPool1WtrTmp Pool1 Water Temp Setpoint °F

AV W 1011 twiSetInpPool2WtrTmp Pool2 Water Temp Setpoint °F

AV W 1012 twiSetInpPurMixBoxPos Purge Mode Mix Box Setpoint %

AV W 1013 twiSetInpRtnAirRelHum Return Air RH Setpoint %

AV W 1014 twiSetInpRtnAirTmp Return Air Temp Setpoint °F

AV R 1015 xwiAuxAirCoolStgRqd Aux Air Cool Requested (Rqd) Stages

AV R 1016 xwiAuxAirHeatStgRqd Aux Air Heat Stages Rqd Stages

AV R 1017 xwiCpr1ModeReq Cmpr1 Mode Requested Stages

AV R 1018 xwiCpr2ModeReq Cmpr2 Mode Requested Stages

AV R 1019 xwiCpr3ModeReq Cmpr3 Mode Requested Stages

AV R 1020 xwiDehStgRqd Dehumidification Stages Rqd Stages

AV R 1021 xwiHeatCoolStgRqd Heat/Cool Stages Rqd Stages

AV R 1022 xwiLastUnitGnlFltCode Last Unit Fault Code See below

AV R 1023 xwiSenGnlFltCode Sensor Fault Code See below

AV R 1024 xwiUnitGnlFltCode Unit Fault Code See below

BV R 1 xbAlarm_DO Alarm Output on/off

BV R 2 xbAuxAirCool1_DO Aux Cool 1 Output on/off

BV R 3 xbAuxAirCool2_DO Aux Cool 2 Output on/off

BV R 4 xbAuxAirCool3_DO Aux Cool 3 Output on/off

BV R 5 xbAuxAirHeat1_DO Aux Air Heat 1 Output on/off

BV R 6 xbAuxAirHeat2_DO Aux Air Heat 2 Output on/off

BV R 7 xbAuxAirHeat3_DO Aux Air Heat 3 Output on/off

BV W 8 xbBASForceNoPurMod Force NoPurge Mode on/off

BV W 9 xbBASForceOccupied Force Occupied on/off

BV W 10 xbBASForcePurMod Force Purge Mode on/off

BV W 11 xbBASForceUnoccupied Force Unoccupied on/off

BV R 12 xbExhFan_DO Exhaust Fan Output on/off

BV R 13 xbOccupied Occupied Mode on/off

BV R 14 xbPool1AuxWtrHeat_DO Pool1 Aux Heat Output on/off

BV R 15 xbPool2AuxWtrHeat_DO Pool2 Aux Heat Output on/off

— BACnet Points List continued

PoolPak MPK series - Page 5
