Potterton Derwent Compact Plus - Flue Box Assembly

SECTION 7 POTTERTON COMMERCIAL PRODUCTS DIVISION
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
PAGE 30
DERWENT COMPACT PLUS - CONDENSING
Flue Box Assembly
6 & 8 Section
Item
No.
Description Qty Part No
1 Welded Flue Box Assembly (6 Sections)
Welded Flue Box Assembly (8 Sections)
1
1
S137507
S137517
2 Flue Box Front (6 Section)
Flue Box Front (8 Section)
1
1
S137500
S137514
3 Trap for Cleaning (6 Sections)
Trap for Cleaning (8 Sections)
1
1
S137502
S137518
4 Flue Box Perforated Plate (6 Sections)
Flue Box Perforated Plate (8 Sections)
1
1
S137647
S137648
6 Left Hand Side Flue Box Insulation (6 Sections)
Left Hand Side Flue Box Insulation (8 Sections)
1
1
S137857
S137860
7 Right Hand Side Flue Box Insulation (6 Sections)
Right Hand Side Flue Box Insulation (8 Sections)
1
1
S137856
S137859
8 Front Side Flue Box Insulation (6 Sections)
Front Side Flue Box Insulation (8 Sections)
1
1
S137855
S137861
9 Back Side Flue Box Insulation (6 Sections)
Back Side Flue Box Insulation (8 Sections)
1
1
S137858
S137862
4 Section
Item
No.
Description Qty Part No
1 Welded Flue Box Assembly (4 Sections) 1 S137670
2 Flue Box Front Panel (4 Sections) 1 S137667
3 Trap for Cleaning (4 Sections) 1 S137666
10 Right Hand Side Flue Box Insulation (4 sections) 1 S137851
11 Left Hand Side Flue Box Insulation (4 Sections) 1 S137852
12 Top Flue Box Insulation (4 Sections) 1 S137852
13 Back Side flue Box Insulation (4 Sections) 1 S137854
6 & 8 Section
4 Section
