Potterton Derwent Compact Plus - Burner Bar Assembly

SECTION 7 POTTERTON COMMERCIAL PRODUCTS DIVISION
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
PAGE 32
DERWENT COMPACT PLUS - CONDENSING
Burner Bar Assembly
Item No. Description Qty Part No
1 (not
shown)
Burner Bar Assembly Condensing 8 Sections UK
Burner Bar Assembly Condensing 4 Sections UK
Burner Bar Assembly Condensing 6 Sections UK
1
1
1
S137589
S137684
S503791
1a Burner Mounting Plate 6 Sections
Burner Mounting Plate 8 Sections
Burner Mounting Plate 4 Sections
1
1
1
S137179
S137181
S137683
2 Burner Bar 120/70 LG4 16 1 S9020400
3 Burner Back Plate 4 Sections
Burner Back Plate 6 Sections
Burner Back Plate 8 Sections
1
1
1
S132465
S132806
S133742
4 Mounting Plate Insulation 8 Sections
Mounting Plate Insulation 4 Sections
Mounting Plate Insulation 6 Sections
1
1
1
S137030
S137032
S137034
4a Top Insulation 4 Sections
Top Insulation 6 Sections
Top Insulation 8 Sections
1
1
1
S135625
S135627
S135629
4b Side Insulation 2 S137100
5 Gas Manifold 6 Sections
Gas Manifold 4 Sections
Gas Manifold 8 Sections
1
1
1
S137580
S17006493
S17006497
6 Burner Injector 7 S174003180
7 Injector Washer 7 S17006504
8 Tap Mini FF 1/8 Cv. Cr.0T58 1 S17006461
8a Elbow for 4 dia. Tube 1 S136479
8b Conical Tap Connection B1 1 S1333831
9 –9a Gas Valve Manifold + Gas Valve Seal 2 S17006302
10 Nut G H 8 x 50 ABIG 6 15236109
10a Washer D 38.5/8.5 6 SN9184110
1 Burner Bar Assembly
24 Pilot Assembly
34 Gas Supply Pipe Assembly
19A
