Replacing grinding stones
Grinding stones must be replaced when their
diameter is 7.5 cm or below.
Lift the top and lock it in the raised position using
the depth limit.
Remove the disc shield (2) by slackening the three
retaining screws (4) and handle (18).
Unscrew the outer flange (a) from the spindle and
remove the grinding disc.
Remove any filings from around the spindle and
flanges.
Fit the new grinding disc, outer flange and
protective shield. Release the depth limit and
lower the top.
Start the chain grinder and let it run freely for a
few seconds to check that the grinding disc is
correctly fitted.
Cleaning and maintenance
The chain grinder can be cleaned by wiping it with
a damp cloth. Grinding dust and filings can be
removed using a brush or compressed air.
Do not use corrosive or abrasive cleaning agents.
Environmental information
You can help protect the environment!
Follow local environmental regulations:
Dispose of unwanted electrical
equipment at an approved refuse
disposal centre.
