16
TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA / TECHNICKÁ SPECIFIKACE
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
BHW30 BHW40 BHW50 BHW60
Ref. nr. 952.180 952.182 952.184 952.186 952.188 952.190 952.192 952.194
Output power: Max
40W
60W
80W
120W
Output power: RMS 20W 30W 40W 60W
Tweeter type
Dome
Diameter tweeter 1/2” 1”
Diameter woofer
3”
4”
5.25”
6.5”
Magnet type Ferrite
Impedance 8 Ohm
Tappings 100V 2.5W, 5W, 10W 5W, 10W, 20W 7.5W, 15W, 30W 10W, 20W, 40W
Tappings 70V
1.25W, 2.5W, 5W
2.5W, 5W, 10W
3.75W, 7.5W, 15W
5W, 10W, 20W
Frequency response 120Hz-20KHz 100Hz-20KHz 75Hz-20KHZ 55Hz-20KHz
SPL @ 1W/1m
91dB
97dB
102dB
105dB
IP rating IPX5
Dimensions (LxWxH)
150x106x114mm
200x140x135mm
250x175x156mm
303x215x190mm
Weight 0,84kg 1,25kg 1,60kg 2,40kg
European Union
United Kingdom
Tronios B.V.,
Bedrijvenpark Twente Noord 18,
7602KR Almelo, The Netherlands
Tronios Ltd.,
130 Harley Street,
London W1G 7JU, United Kingdom
2014/35/EU
S.I. 2016:1101
2014/30/EU
S.I. 2016:1091
2011/65/EC
S.I. 2012:3032
Specifications and design are subject to change without prior notice.
