Power Dynamics PD615SA User Manual

14
TECHNICAL SPECIFICATION / TECNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
PD615SA
PD618SA
Ref.nr:
178.981
178.984
Peak power
1000W
1400W
Power max
500W
700W
Power RMS
400W
500W
Internal amplifier
Class D
Class D
Impedance
8 Ohm
8 Ohm
Frequency Response
50Hz – 300Hz
50Hz – 300kHz
Sensitivity
101dB
101dB
SPL Max
128dB
130dB
Woofer
15”
18”
Rated voltage
AC 240V~ 50Hz
AC 110-240V~ 50Hz
Fuse
T3.15A
T4A
Weight
27.9kg
30.9kg
Dimensions
555 x 440 x 528mm
600 x 510 x 610mm
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.

Power Dynamics PD615SA Specifications

General

Brand	Power Dynamics
Model	PD615SA
Category	Subwoofer
Language	English
