Power Dynamics PDD500 User Manual

Specifications / Technische Daten / Specificaties / Especificaciones
Specification
PDD500
PDD900
PDD1200
Ref. No.
171.240
171.243
171.246
4 Ohm Stereo Power
(RMS)
2x 250W
2x 450W
2x 600W
8 Ohm Stereo Power
(RMS)
2x 150W
2x 250W
2x 350W
8 Ohm Bridge Power
(RMS)
500W
900W
1200W
Frequency Response
20Hz – 50kHz (±1.5dB)
Input Sensitivity
770mV
Maximum Input Level
21dBv/9v
Input Impedance
20kOhm
Signal/Noise Ratio A-
weighted RMS
>90dB
Crosstalk @
Rated Output Power 8
Ohm / 1kHz
>70dB
Damping Factor @ 8
Ohm / 1kHz
>350
Slew Rate Internal
40V/µS
Protection
Short Circuit, Clip and Power limiter, AC Line
Fuse, Thermal Cut Off, Slow Start
Power Supply
Switch mode 230Vac, 50Hz
Dimensions (bxhxd)
482 x 212 x 44mm (19” x 1U)
Weight
3.6kg
3.6kg
3.6kg

Power Dynamics PDD500 Specifications

General

Brand	Power Dynamics
Model	PDD500
Category	Amplifier
Language	English
