Power Dynamics PDS40 User Manual

9
TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Output Power: RMS : 30W
Diameter tweeter : 1”
Diameter woofer : 5.25”
Tweeter type : Mylar
Magnet type : Ferrite
Power Tappings : 3.75W, 7.5W, 15W, 30W
Impedance : 100V, 70V, 8Ohm
Frequency response : 70Hz - 20kHz
SPL @1W/1m : 89dB
Dimensions : Ø220 x 210mm
Weight (kg) : 2,00 kg
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
• Low Voltage (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC) 2014/30/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU

Power Dynamics PDS40 Specifications

General

Brand	Power Dynamics
Model	PDS40
Category	Speakers
Language	English
