Power Dynamics WS40A User Manual

3
OVERVIEW
1. Power switch
2. DC Power connector
3. Speaker output connector for passive speaker
4. Infrared receiver and LED indicator
CONNECTION
Connect the DC adapter to the speakers and connect to the 110V~230V AC power. Then you can turn on power switch. The
status indicator LED will be red and fast blinks, after about 10 seconds the speaker will sound a tone, it means the speaker is
ready.
DOWNLOAD AND INSTALL MUZO PLAYER APP
Download the Muzo Player app via Apple store or Google play.
MUZO Player Apple Store MUZO Player Google Play
Open the Muzo Player app on your smart phone, the APP will automatically search for speakers. And then you can follow the
wizard step by step to complete the speaker settings, check the last page of manual.
Power ON / OFF
Short press for join the speaker group
Long press for exit the speaker group
No function
Volume UP
Volume Down
Previous
Play / Pause
Next
Switch UP for the predefined Channel
Switch Down for the predefined Channel
BT
Short press for switch to the BT play mode
Long press for switch to the BT pair mode
Short press for connect the speaker to the WIFI
Long press for restore to the factory settings
Switch between BT and WIFI

Power Dynamics WS40A Specifications

General

Tweeter	Yes
Speaker type	2-way
Tweeter diameter	25.4 mm
Number of drivers	2
Speaker placement	Wall-mountable
Audio output channels	- channels
Mid-range driver diameter	101.6 mm
Number of tweeter drivers	1
Tweeter diameter (imperial)	1 \
Mid-range driver diameter (imperial)	4 \
Connectivity technology	Wireless
Impedance	8 Ω
Sensitivity	87 dB
Frequency range	100 - 20000 Hz
RMS rated power	240 W
Product color	White
Recommended usage	Universal
Quantity per pack	2 pc(s)
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	180 mm
Width	155 mm
Height	235 mm
Weight	3600 g
