T OUROFMAXX1500-SERIESINVERTER
AC power is supplied via three North American, household-type receptacles as
showninFIGURE1.Thisallowstheconnectionandoperationofmost120VAC-
poweredelectricalandelectronicappliancesthatuseastandardplug.Therestof
the front panel items are: One FAULT LED. When this lights, the inverter is shut
down.OnePOWER LEDthatlightswhen theinverterisoperating. OneON/OFF
switchthatshutsoffallinverterfunctions.TheON/OFFswitchcanalsobeusedto
reset the inverter after the inverter shutsdown due to a fault condition such as
overload,overtemperature,shortcircuitorhighvoltage.
FIGURE1-FRONT PANEL
FIGURES2A -SIDEVIEW FIGURES2B-CABLES
4
AC
OUTLET
FANS
GROUNDING
TERMINAL
FAULT LED
(Red)
POWERLED
(Green)
ON/OFF
SWITCH
POSITIVE
(+)TERMINAL
NEGATIVE(-)
TERMINAL
DCINVERTER
TERMINAL
CONNECTIONS
RING
TERMINALS
TODC
BATTERY
POWER
METER
MOUNTING
BRACKETS
MOUNTING
BRACKETS
