Power Step Cat D10R Dozer - Page 2

Pg2
PSA-D10R FL+RHW 31-3-14
FOLDING LADDER
Caterpillar D10R Dozer
CONTENTS
Page 3 Section 1 Installation and Mounting instructions
Installation Drawings
10 Section 2 Electrical System W
iring Diagrams
15 Section 3 Recommended Maintenance procedure
16 Section 4 Operating Procedure
Section 5 Drawings and Repair Parts lists
17 5 Assembly Complete
18 5-1 Ladder Assembly
Parts List
19 5-2 Landing Assembly LHS (+ NG Version)
Parts Lists
23 5-3 Landing Assembly RHS (+ NG Version)
Parts Lists
27 5-4 Landing Assembly Rear (+ NG Version)
Parts List
29 5-5 Spreader Assembly
Parts List
31 5-6 Drive Unit Assembly
Parts List
33 5-7 PROP Assembly
Parts List
34 5-8 Hydraulic Cylinder
Parts List
Valve Diagram
36 5-9 Power Pack
Parts List
39 5-10 Electrical Controls
Parts List
Material Kit Supplied
