OPERATING SPECIFICATIONS
3
OPERATING SPECIFICATIONS
Working Dimensions
Maximum working height: 4.20 m
Maximum platform height: 2.20 m
Platform dimensions: 850 mm (L) x 644 mm (W)
Working footprint: 1280 mm x 740 mm
Safe working load: 150 kg (1 person + tools)
Maximum manual force: 200 N
Maximum gradient for operation: 0 degrees
Maximum wind force: Internal use only,
0 (zero) mph
Maximum wheel force: 234 kg (2.29 kN)
Maximum castor point load: 234 kg (2.29 kN)
Sound pressure level: Less than 70dBA
Closed Dimensions
Length: 1280 mm
Width: 740 mm
Height: 1950 mm
Weight: 305 kg
Lift Cycles: Unlimited, subject to maintenance
program being adhered to.
2.0m
1.0m
4.2m
3.0m
