Powernail 2000 - INTRODUCTION; LIMITED WARRANTY; MODEL 2000 SCHEMATIC

2
The Model 2000 trigger-pull nailer is designed to bring Powernail quality and fl ooring expertise
to a pneumatic nailer. The Model 2000 is designed for use with 1” and 1-1/4”, 20 gauge L-Cleat
Powernails
®
. The Model 2000 nails from 5/16” to 9/16” fl ooring through the use of a FLEX
adjustable foot assembly that can be adjusted to fi t different fl ooring profi les.
INTRODUCTION
INDEX
LIMITED WARRANTY
POWERNAIL® Company, Inc. warrants to its customer, and to the fi rst end-use
purchaser of POWERNAIL Model 2000 POWERNAILER purchased from an authorized
POWERNAIL distributor, that each serialized manufactured Model 2000 POWERNAILER
by POWERNAIL®, for a period of 12 months from the date of purchase; shall be free
of defects in materials and workmanship and will meet POWERNAIL’S specifi cations in
effect at the time of product shipment. POWERNAIL will repair or replace, at its option,
any Model 2000 POWERNAILER that does not conform to this warranty. Claims must be
made no later than fi fteen (15) days after the end of the warranty period. POWERNAIL will
perform all repair or replacements itself or through its authorized contractors. POWERNAIL
is not responsible for shipping, labor or other direct or indirect costs. Damage caused by
abuse, misuse, unusual or excessive wear is excluded. Repair or modifi cation of the Products
by unauthorized parties will void this warranty. The customer is responsible for returning
Products to POWERNAIL for verifi cation of nonconformance. Warranties for Products not
manufactured by POWERNAIL are limited to warranties provided to POWERNAIL by the
manufacturer of such product that are assignable to customer.
THESE WARRANTIES AND REMEDIES ARE EXCLUSIVE OF ALL OTHERS,
EXPRESS OR IMPLIED. THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR PURPOSE ARE EXPRESSLY EXCLUDED. IN NO EVENT SHALL
POWERNAIL’S LIABILITY FOR A WARRANTY CLAIM EXCEED THE PRICE PAID
TO POWERNAIL FOR THE NONCONFORMING PRODUCT, REGARDLESS OF THE
FORM OR BASIS OF THE CLAIM OR CAUSE OF ACTION.
Index..................................... 2
Warranty............................... 2
Operating the tool................. 4-6
Air Supply............................. 5
Safety Labels........................ 7
Maintenance......................... 7
Clearing a jam...................... 8
Troubleshooting Chart.......... 9
Schematic / Parts List.......... 10-11
Nail Depth Chart..................... 12
Phone Support..................... 12
Web Site.............................. 12
Powernail Company Info..... 12
11
MODEL 2000 SCHEMATIC
46
44
27
65
18R1
18L
59
61
60
58
47
46
45
43
57
48
49
56
51
50
76
42
75
80
77
73
78
71
72R1
74
