Powersmart DB8620 - Page 21

21
Front Wheel Assembly
Item
Stock#
Description
Qty
Item
Stock#
Description
Qty
1 303020503 Bolt M6x35 3 11 303020167
Square neck bolt
M6x36
4
2
303020282
Bolt M6x16
1
12
303160617A
Front wheel stents
1
3 303041009 Spring washer 6 1 13 303020384
Square neck bolt
M8x95
1
4
303042021
Flat washer 6
1
14
303050007
Collar 12
2
5
303070978
Mounting plate
2
15
303060103A
Front wheel sleeve
1
6
303060108
Bearing bracket
1
16
203040020A
Front wheel
1
7
303070977A
Front wheel support
1
17
303100066
Plastic bearing
2
8 303100071
Ball bearing
61902-2Z
2 18 203020865A Knob 1
9
303030032
Nylon nut M6
7
19
303030036
Nylon nut M8
1
10
303042021
Flat washer 6
4
