Powersmart PS431 - Page 18

18
Engine parts list
Item
Stock #
Description
Qty
Item
Stock #
Description
Qty
1 100002804 Breather Hose 1 48 100010576 Woodruff Key 1
2
100010417-0001
Screw M5×15
16
49
100003055
Piston
1
3
100002301
Valve Cover
1
50
100003218
Circlip
2
4
100002788
Oil Block
1
51
100003112
Piston Pin
1
5 100011001-0001 Screw ST4.2×10 1 52 100003227 Piston Ring Set 1
6
100010128
Valve Cover Gasket
1
53
100003134
Piston Ring 1st
1
7
100004416
Rocker Arm Assembly
2
54
100003176
Piston Ring 2nd
1
8 100004487 Lock Nut 2 55 100030448 Oil Ring 1
9
100030648
Adjust Nut
2
56
100010135
Crankcase Gasket
1
10
100004463
Upper Rocker Arm
2
57
100010668
Bearing 6002
1
11 100004481 Pin 1 58 100002919 Crankcase Cover 1
12
100004387
Push Rod
2
59
100004096-0001
Dipstick Assembly
1
13
100009371
Spark Plug
1
62
100010419-0001
Screw M5×28
1
14
100004577
Valve Spring Seat
2
63
100017615
Oil Seal 15×26×5
2
15
100004560
Valve Spring
2
64
100010911-0003
Washer 8
1
16
100002362
Cylinder Head
1
65
100007541
Starter Cup
1
17
100010383-0001
Stud M5×54
2
66
100007181-0002
Recoil Starter Assembly
1
18 100006544 Muffler Gasket A 2 77 100004350 Camshaft Pin 1
19
100006547
Muffler Gasket B
1
78
100004273
Camshaft
1
20
100010420-0001
Screw M5×10
1
79
100004352
Camshaft Cover
1
21
100006155
Muffler
1
80
100004373
Release Valve
1
22
100011451-0002
Nut M5
8
81
100004382
Return Spring
1
23
100005549
Insulator Gasket A
1
82
100004329
Drive Timing Gear
1
24
100011146-0001
Bolt M5×55
2
83
100002590
Crankcase
1
25
100005583
Insulator
1
84
100009481
Flywheel
1
26
100010418-0001
Screw M5×20
5
85
100007070
Flywheel Cover
1
27
100005165
Carburetor
1
86
100011456-0002
Nut M10×1.25
1
28 100005663 O-Ring 1 87 100010422-0001 Screw M5×13.5 2
29
100004627-0002
Air Filter Assembly
1
88
100007165-0002
Shroud
1
30
100005791
Choke Lever
1
89
100007741
Clutch Assembly
1
31 100004963 Air Filter Base 1 95 100006570-0001 Muffler Plate 1
32
100005711
Choke Plate
1
97
100008744
Fuel Cap
1
33
100051870
Air Filter Base
1
98
100008815
Plug
1
34
100004804
Air Filter Element
1
99
100031375
Fuel Cap Cover
1
35
100004823
Air Filter Cover
1
100
100008793
Fuel Cap Gasket
1
36
100004957
Bolt
1
101
100021457
Plug
1
37
100009184
Ignition Module
1
102
100008538
Fuel Tank
1
38 100004483 Pin 1 103 100017667 Fuel Hose 2.5×5.3×230 1
39
100010539
Washer 6
1
104
100017668
Fuel Hose 2.5×5.3×270
1
40
100011528-0003
Bolt M6×10
1
105
100010813
Washer 5
4
41
100004464
Lower Rocker Arm
2
106
100009032
Float Filter
1
42
100004517
Intake Valve
1
107
100009031
Float
1
43
100004540
Exhaust Valve
1
108
100008927
Damping Pad
3
44
100010190
Cylinder Head Gasket
1
109
100008661
Fuel Tank Guard
1
45
100010403-0001
Stud M5×30
4
110
100010417-0001
Screw M5×15
4
46
100010542
Pin 4×8
4
111
100030031
Insulator Gasket B
1
47
100003412
Connecting Rod
1
