Powersmart PS6300 - Pressure Control Knob; SET UP; TO RELIEVE SPRAYER PRESSURE

13
Pressure Control Knob
The Pressure Control Knob can be adjusted for High Pressure Spraying,
Low Pressure Spraying, Priming/Cleaning, or Rolling.
Align the Pressure Control Knob with indicator on the Sprayer Housing
to
set the function.
SET UP
Noted: Remove or cover objects that you want to protect from overspray (paint mist).

Connect paint hose to paint
hose outlet. Use wrench to
tighten securely.

Attach paint hose to paint
gun and tighten with two
wrenched.

Turn pressure control knob
to low pressure spray
setting.
TO RELIEVE SPRAYER PRESSURE
1. Turn power switch off and unplug unit from
outlet.
2. Switch prime/spray switch to prime mode.
3. Point gun into paint pail and activate sprayer
trigger to relieve pressure.
4.Turn trigger lock knob to locking position.
Note: Always set to prime mode between uses.
Prime
Unlock
Lock
