PowerStation PS5000M - Additional Unit Components & Connections

PS5000M Owners Manual Page 6
030907
S.
T.
O. O.
P.
GETTING TO KNOW YOUR PS5000M continued
Figure 3
O. 12V DC power socket
P. Solid-state, integrated AC charger port
Q. Positive clamp
R. Negative clamp
S. 12V DC power cable
T. 120V AC charger cable
U. Air inlet adaptors
EWARNING E
Always wear eye protection when using your 140 PSI
compressor unit. Always follow vehicle / tire manufacturer’s
recommendation for proper inflation. DO NOT OVER-INFLATE.
When inflating tires, always lock the air hose connector over the
inflation valve before moving the “ON/OFF” switch to the “ON” position.
Air pressure already present will be registered on the built-in air pressure
gauge. Run compressor for only 10 minute intervals, allowing 10 minute
rests between intervals to prevent the compressor from overheating.
NOTE: Failure to follow these instructions may cause
permanent injury or damage.
R.
Q.
U.
