129
第
十
章
Chapter 7
Chapter 7 Dimension
7-1.Dimension
7-1-1.Product outside drawing, installation size
Nameplate
Cooling fan
operation
panel
Upper cove plate
Upper cover plate
retaining screw
Cable inlet
Air duct inlet
Drawing 7-1:Product outside drawing, installation dimension
7-1-2.PI500 series
A
B
φd
H1
H
W
D
D1
Drawing 7-2:8.5-200kW dimension
