Powtran PI500 series User Manual

Chapter 5 Function parameter
28
Chapter 5
E2
PID function group
To set Built-in PID parameters
E3
Virtual DI, Virtual DO
Virtual I/O parameter setting
b0
Motor parameters
To set motor parameter
y0
Function code management
To set password, parameter initialization and parameter
group display
y1
Fault query
Fault message query
5-1-1.d0Group - Monitoring function group
No.
Code
Parameter name
Setting range
Factory
setting
0.
d0.00
Running frequency
Actual output frequency
0.01Hz
1.
d0.01
Set frequency
Actual set frequency
0.01Hz
2.
d0.02
DC bus voltage
Detected value for DC bus voltage
0.1V
3.
d0.03
output voltage
Actual output voltage
1V
4.
d0.04
output current
Effective value for Actual motor current
0.01A
5.
d0.05
output power
Calculated value for motor output power
0.1kW
6.
d0.06
output torque
Motor output torque percentage
0.1%
7.
d0.07
DI input status
DI input status
-
8.
d0.08
DO output status
DO output status
-
9.
d0.09
AI1 voltage (V)
AI1 input voltage value
0.01V
10.
d0.10
AI2 voltage (V)
AI2 input voltage value
0.01V
11.
d0.11
AI3 voltage (V)
AI3 input voltage value
0.01V
12.
d0.12
Count value
Actual pulse count value in counting
function
-
13.
d0.13
Length value
Actual length in fixed length function
-
14.
d0.14
Actual operating speed
Motor actual running speed
-
15.
d0.15
PID setting
Reference value percentage when PID runs
%
16.
d0.16
PID feedback
Feedback value percentage when PID runs
%
17.
d0.17
PLC stage
Stage display when PLC runs
-
18.
d0.18
High-speed pulse input
frequency
High-speed pulse input frequency display,
unit: 0.01Khz
0.01kHz
19.
d0.19
Feedback
speed(unit:0.1Hz)
PG feedback speed, to an accuracy of 0.1hz
0.1Hz
20.
d0.20
Remaining run time
Remaining run time display, it is for timing
run control
0.1Min
