Chapter 4 Installation and commissioning
22
Wiring must be performed by a professional trained personnel, or this may cause damage to the
equipment and personal injury!
Must be grounded firmly, otherwise there is a danger of electric shock or fire hazard !
Make sure that the input power is consistent with the rated value of inverter, otherwise which
may cause damage to the inverter!
Make sure that the motor matches the inverter, otherwise which may cause damage to the motor
or activate the inverter protection!
Do not connect power supply to U, V, W terminals, otherwise which may cause damage to the
inverter!
Do not directly connect braking resistor to DC bus (P), (+) terminals, otherwise which may cause
a fire!
※The U,V,W output end of inverter can not install phase advancing capacitor or RC absorbing
device. The inverter input power must be cut off when replacing the motor
※Do not let metal chips or wire ends into inside the inverter when wiring, otherwise which may
cause malfunction to the inverter.
※Disconnect motor or switch power-frequency power supply only when the inverter stops output
In order to minimize the effects of electromagnetic interference, it is recommended that a surge
absorption device shall be installed additionally when electromagnetic contactor and relay is closer
from the inverter.
※External control lines of inverter shall adopt isolation device or shielded wire.
※In addition to shielding, the wiring of input command signal should also be aligned separately, it
is best to stay away from the main circuit wiring.
※If the carrier frequency is less than 3KHz, the maximum distance between the inverter and the
motor should be within 50 meters; if the carrier frequency is greater than 4KHz, the distance
should be reduced appropriately, it is best to lay the wiring inside metal tube.
※When the inverter is additionally equipped with peripherals (Filter, reactor, etc.), firstly measure
its insulation resistance to ground by using 1000 volt megger, so as to ensure the measured value is
no less than 4 megohms.
※When the inverter need to be started frequently, do not directly turn power off, only the control
terminal or keyboard or RS485 operation command can be used to control the start/stop operation,
in order to avoid damage to the rectifier bridge.
※To prevent the occurrence of an accident, the ground terminal( )must be earthed firmly
(grounding impedance should be less than 10 ohms), otherwise the leakage current will occur.
※The specifications on wires used by the main circuit wiring shall comply with the relevant
provisions of the National Electrical Code.
※The motor's capacity should be equal to or less than the inverter's capacity.
