Powtran PI500-W Series User Manual

Chapter 5 Function parameter
40
Chapter 5
selection
251
E3.03
Virtual VDI4
terminal function
selection
Same as F1.00 to F1.07
0
★
252
E3.04
Virtual VDI5
terminal function
selection
Same as F1.00 to F1.07
0
★
253
E3.05
Virtual VDI
terminal status set
Units digit:Virtual VDI1
Tens digit:Virtual VDI2
Hundreds digit:Virtual VDI3
Thousands digit:Virtual VDI4
Tens of thousands:Virtual VDI5
00000
☆
254
E3.06
Virtual VDI
terminal effective
status set mode
Units digit:Virtual VDI1
Tens digit:Virtual VDI2
Hundreds digit:Virtual VDI3
Thousands digit:Virtual VDI4
Tens of thousands:Virtual VDI5
11111
★
255
E3.07
AI1 terminal as a
function selection
of DI
Same as
F1.00 to F1.07
0
★
256
E3.08
AI2 terminal as a
function selection
of DI
Same as
F1.00 to F1.07
0
★
257
E3.09
Reserved
258
E3.10
AI as DI effective
mode selection
Units digit:AI1
0:High level effectively
1:Low level effectively
Tens digit:AI2(0 to 1,same as units digit)
Hundreds digit:AI3(0 to 1,same as units digit)
000
★
259
E3.11
Virtual VDO1
output function
selection
Same as
F2.01 to F2.05
0
☆
260
E3.12
Virtual VDO2
output function
Same as
F2.01 to F2.05
0
☆
261
E3.13
Virtual VDO3
output function
Same as
F2.01 to F2.05
0
☆
262
E3.14
Virtual VDO4
output function
Same as
F2.01 to F2.05
0
☆
263
E3.15
Virtual VDO5
output function
Same as
F2.01 to F2.05
0
☆
264
E3.16
VDO output
terminal effective
status selection
Units digit:VDO1; 0:Positive logic
1:Negative logic
Tens digit: VDO2(0 to 1,same as above)
Hundreds digit:VDO3(0 to 1,same as above)
Thousands digit:VDO4(0 to 1,same as above)
Tens of thousands digit:VDO5(0 to 1,same as
above)
00000
☆
265
E3.17
VDO1 output
delay time
0.0s to 3600.0s
0.0s
☆
