Powtran PI9000 series - Output Filter

Chapter 10 Options
209
14
NFI-
600
690
215 to 250
600
14.2
470/245/128
165/245
10-10.Output filter
10-10-1.Output filter(380v)
No.
Model
Voltage(V)
Power(KW)
Current(A)
Net
weight(kg)
Dimensions
L/W/H(mm)
Installation
size
W1/H1
(mm)
1
NF0-
005
380
0.75 to 1.5
5
0.75
135/105/44
51/95
2
NF0-
010
380
2.2 to 4
10
1.25
202/86/58
184/60
3
NF0-
020
380
5.5 to 7.5
20
1.47
202/86/58
184/60
4
NF0-
036
380
11 to 15
36
2.35
215/100/70
200/70
5
NF0-
050
380
18.5 to 22
50
2.37
215/100/70
200/70
6
NF0-
065
380
30
65
2.73
261/100/90
243/70
7
NF0-
080
380
37
80
3.19
261/100/90
243/70
8
NF0-
100
380
45
100
3.34
261/100/90
243/70
9
NF0-
150
380
55 to 75
150
5.04
320/190/90
180/175
10
NF0-
200
380
93
200
4.58
320/190/90
240/175
11
NF0-
250
380
110 to 132
250
6.9
380/210/90
180/195
12
NF0-
300
380
160
300
7.2
380/210/90
180/195
13
NF0-
400
380
200
400
13.2
14
NF0-
600
380
215 to 250
600
13.4
320/260/128
165/245
10-10-2.Output filter(690v)
No.
Model
Voltage(V)
Power(KW)
Current(A)
Net
weight(kg)
Dimensions
L/W/H(mm)
Installatio
n size
W1/H1
(mm)
