Powtran PI9000 series User Manual

Appendix I
227
When F9.05
is set to 1:
ADR
01H
CMD
03H
Byte number
04H
Data F002H high-order
00H
Data F002H low-order
00H
Data F003H high-order
00H
Data F003H low-order
01H
CRC CHK low-order
CRC CHK values are to be calculated
CRC CHK high-order
Command Code: 06H, write a word. For example:Write 5000(1388H)into the address F00AH
of the inverter with slave address 02H.
Master command information
ADR
02H
CMD
06H
Data address high-order
F0H
Data address low-order
13H
Data content high-order
13H
Data content low-order
88H
CRC CHK low-order
CRC CHK values are to be calculated
CRC CHK high-order
Slave responding information
ADR
02H
CMD
06H
Data address high-order
F0H
Data address low-order
13H
Data content high-order
13H
Data content low-order
88H
CRC CHK low-order
CRC CHK values are to be calculated
CRC CHK high-order
I-2 Check mode:
Check mode - CRC mode: CRC (Cyclical Redundancy Check) adopts RTU
frame format, the message includes an error-checking field that is based on CRC
method. The CRC field checks the whole content of message. The CRC field has
two bytes containing a 16-bit binary value. The CRC value calculated by the
transmitting device will be added into to the message. The receiving device
recalculates the value of the received CRC, and compares the calculated value to the
Actual value of the received CRC field, if the two values are not equal, then there is
an error in the transmission.
The CRC firstly stores 0xFFFF and then calls for a process to deal with the
successive eight-bit bytes in message and the value of the current register. Only the
