Powtran PI9000 series - Appendix IV CAN Bus Communication Card Use Description

Appendix IV
242
第
十
章
Appendix IV CAN bus communication card use description
IV-1.Overview
CAN bus communication card is suitable for all series of PI9000 frequency
inverters.Protocol details,please refer to《CAN bus communication protocol》
document.
IV-2.Mechanical installation and terminal functions
IV-2-1 Mechanical installation modes:
Diagram 2.1 CAN bus communication card‟s installation on SCB
Diagram 2.2 CAN bus communication card‟s installation on LCB
IV-2-2 Terminal function
