PPA CODIGUS 4D PLUS User Manual

#4321 20 1 # #
ProgAccess. Index LEDSector1on=Enablesbeeps
LEDSector1o=Disablesbeeps
Conrm Outprog.
PANIC VIA REMOTE CONTROL
a)Pressaregisteredbuttonontheremotecontrolformorethan3seconds.
b)Theboardwilldialtotheregisteredphonesand,dependingonthe
conguration,itcantriggerthesirenfor5minutes(audiblepanic).
Whenthefunctionissettosilentpanic,theboardwillonlydialtothe
phones,notbytriggeringthesiren.Tocongure,type:
#4321 21 1 # #
prog.access Index LEDSector1on=Silentpanic
LEDSector1o=Audiblepanic
Conrm OutProg
IMMEDIATE PANIC:
Registeraremotecontrolwith4blanksectors(nosectorselected)
anditwillonlyworkasapanicwithonly1click.
SIRENE TIME
Tosetthesirenalarmtime,type:
#4321 22 2digits #
prog.access Index Time(up00to99minutes) OutProg
Thefactorydefaultsettingis05 minutes.Whenthetimeissetto00,
thefunctionwillbedisabled.
LOW BATTERY WARNING (WIRELESS SENSORS)
Thesirenreportsthelowbatterywarningofwirelesssensorswitha
longbeepafterthebeeporarmbeepsindicatingthatthebatteryof
awirelesssensorislowandneedstobereplaced.Factorydefaultis
enabled,butthisfeaturecanbedisabled.
#4321 23 1 # #
prog.access Index LEDSector1on=Enablebeeps
LEDSector1o=Disablebeeps
Conrm OutProg
IMPUT A/D - ARM AND DESARM (OPTIONAL
DEVICE)
Theboardhasaninputthatallowsarminganddisarmingbyexternal
device.Thisinputcanbeconguredashold(forexternalkeyuse)or
pulse(forexternalbuttonuse).Factorydefaultisretention.
#4321 24 1 # #
prog.access Index LEDSector1on=Retention
LEDSector1o=Pulse
Conrm OutProg
CALLING SERVICE - NUMBER OF RINGS
Theboardcananswercallsandacceptspeciccommandsbyphone
orcell. Thefactorydefault is00 (function disabled),but itcanbe
enabledbychangingthisvaluefrom00 to 99 rings.
#4321 25 2digits # #
prog.access Index Rings#(up00to99) Conrm OutProg
Aftertheboardanswersandvalidatesthepassword,thefollowing
commandsarepossible:
KEY 1
BOARDSTATUS-ONEBEEPFORARMEDANDTWOBEEPS
FORDISARMED
KEY 2 BOARDARM
KEY 3 BOARDDISARMED
KEY 4
PGMSTATUS-ONEARMEDBEEPANDTWOBEEPSFOR
DISARMED
KEY 5 PGMACTIVE
KEY 6 DISABLESPGM
KEY 7 ACTIVEPGMWITHTIMING
PS: PGM commands require PGM MODE to be set before and PGM
TIME.
OUTPUT LED/PGM EXTERNAL
Theboardhasa12 Voltoutputforthecontrolofan externalLED
oraPGMmodule.Themodeandtheoperatingtimecanbeset.The
factorydefaultisMODE 01(followsarming/holdingbyhold)andthe
timeis000(timedisabled).
#4321 26 2digits # #
prog.access Index Mode01to06 Conrm OutProg
MODE MEANING
01 Followsarm/disarmwithretention
02 Followsarm/disarmwithtimedpulse
03 Followsalarmsoundwithretention
04 Followsalarmsoundwithtimedpulse
05 Telephonecallcommand
06
Followviolationofthesector4withtimed
pulse(chime)
#4321 27 3digits # #
prog.access Index Time(000to999sec) Conrm OutProg
TIME SECTORS
Individuallyenablesthesectorsthatwillbetimed,ie,thesectorsthat
willacceptinputtimeandoutputtime.Factorydefaultisallsectors
disabled.
#4321 28 Select1ormoresectors(1to4) # #
prog.
access
Index LEDSectoron=Sectorenabledforcommand
LEDSectoro=Sectordisabledforcommand
Conrm Out
Prog
AUTOMATIC REARM
When disarming, it allows the board to reset if there is no sector
opening(breach)withintheprogrammedperiod.
Thefactorydefaultsettingis00(disabled)andcanbesetfrom00 to
99 seconds.
#4321 29 2digits # #
prog.access Index Time(up00to99sec) Conrm OutProg
INTELLIGENT SECTORS
Theboardcanbeconguredforsmartsectorswhereasectortobe
violatedtwicewithinatimescheduledtoconsideravalidviolation.
Theboardalsoconsidersasviolationasectorthatstaysopenbythe
scheduledtimeortwodierentsectorsthatgoowithinthetime.
Somesectorscanbeconguredtobesmartandotherstofunction
normally.
Thedefaultisdisabledforallsectors.
#4321 30 Select1ormoresectors(1to4) #
prog.
access
Index LEDSectoron=enabledsector
LEDSectoro=disabledsector
Conrm
#4321 31 2dígits # #
prog.
access
Index Time(up00to99s) Conrm OutProg
PERSISTING OR INTERRUPTED TELEPHONE CALL
Whentriggered,theboardstartsthetelephonedialingcycle.This
telephonetripcanbeinterruptedwiththesiren(interruptmode)or
persistuntiltheendofthedialingcycle(persistentmode).
Thefactorydefaultisinterruptmode(LED sector 1 o).
#4321 32 1 # #
prog.access Index LEDSector1on=PersistentMode
LEDSector1o=UninterruptedMode
Conrm OutProg
ARMING AND DESARMING THE BOARD
Theboardalarmcanonlybearmedwhenallsectorsareclosed(sector
LEDsclearedonthepanel).
BY REMOTE CONTROL:
a)Pressthebuttonoftheregisteredcontrol.
b)Allsectorsassignedtothisbutton(duringthecontrolregister)will
bearmedordisarmed.
c)Whenarmed,therespectivesectorLEDs will ash.
NOTE: It is possible to divide the sectors so that they are armed
and disarmed through dierent buttons on the remote control.
BY KEYBOARD:
a)Entertheuserpassword(4digits).
b)Allsectorsofthesystemwillbearmedordisarmed.
c)Whenarmed,thesectorLEDswillash.
ABORTING SECTORS:
Toarmonlythedesiredsectors,cancelingtheothers,type:
E 4digits Selectsectorstocancel(from1to4) #
Start User
password
LEDSector1on=Enable
LEDSector1o=Disable
Conrm
NOTE: After the board has been disarmed, all sectors that have
been deleted will automatically reenter the alarm.
BY REMOTE KEY (OPTIONAL):
To arm the panel:
a)Turnonthekey.
b)Allsectorswillbearmed.Ifthereissomeunarmedsector,itwill
arm.Ifallsectorsarealreadyarmed,anewarmwillbesignaled.
c)ThesectorLEDswillash.
To disarm the panel:
a)Turnotheswitch.
b)All sectorswill be disarmed. If there is any armed sector, it will
disarm. If all sectors are already disarmed, a new disarm will be
signaled.
BY PHONE CALL:
Setthenumberofringstoansweracallontheprogramming index
25.
a)Calltheboard(whenanswering,theboardwillrespondwithtwo
beeps).
b)Enterthepasswordoftheuserbythetelephoneorcellphonewho
isthesameoneusedtoarmtheboardbykeyboard(theboardwill
respondwithashort conrmation beepifthepasswordiscorrector
along error beepifthepasswordisinvalid).
c)Aftervalidatingthepassword,enter 1 to hear the status of the
board (the boardwill respond with 1 beep if armed or 2 beeps if
disarmed).
d)Enter2tosettheboardor3todisarm.
SECTOR VIOLATION (ALARM CLOCK)
Whenasectorisviolatedandrestoredshortly,thesirenwillremain
ringingfortheprogrammedtimeand2dialcycleswillbeperformed.
Then the board returnstoits normal state. If the breachedsector
remainsopen,theboardwillcontinuetodialandsoundthesirenuntil
thesystemisdisarmedorthesectorisclosed.
VIOLATION MEMORY
Informswhichsectorswereviolatedbeforethelastdisarmamentof
thesystem.
a)Intheusermode(Line LED o),presstheP key.
b)TheLEDsofthebreachedsectorswilllightup.
c)Toreturntothenormaloperatingmode,pressanykey.
NOTE: When the board is disarmed, if there is an triggered alarm,
4 beeps will be issued, indicating to the user the violation.
LEDS OF THE BOARD
BoardLEDssignalsystemconditions:
SECTORS LEDS MEANING
OFF CLOSEDSECTOR
ON OPENSECTOR
FLASH ARMEDSECTOR
LED LINE MEANING
OFF INACTIVECOMMUNICATION
ON COMMUNICATIONINPROGRESS
FLASH ACCESSTOTHEPROGRAMMINGMODE
SOUND INDICATION OF THE BUZZER
The board has an internal buzzer that indicates the operations
performedbythekeyboard:
BUZZER MEANING
1SHORTBEEP Keypressed
3SHORTBEEPS
Conrmationnotice(thecommand
ortypedsequencewasaccepeted)
1LONGBEEP
Errortone(thecommandorTyped
sequencewasrejected)
SOUND INDICATION OF THE SIREN
Itinforms,throughbeepsinthesiren,thefollowingsituations:
BEEPS OF THE SIREN MEANING
1BEEP Disarmedboard
2BEEPS Armedboard
3SHORTBEEPS
Armingfailed(attempttoarmwith
theopensectors)
4BEEPS
Disarmedwithviolationmemory
(therewasshootduringthearm
period)
1LONGBEEPAFTER
ARMORDESARM
Lowbatteryof1ormoresensors
Wirelessregistered
CONNECTION
TRANSFORMER CONNECTION
VOLTAGE WIRES TO USE
110V BlackandWhite
220V BlackandRed
INDEX TABLE
INDEX DESCRIPTION FACTORY DEFAULT
01 Telephonememory01 <empty>
02 Telephonememory02 <empty>
03 Telephonememory03 <empty>
04 Telephonememory04 <empty>
05 Telephonememory05 <empty>
06 Telephonememory06 <empty>
07 Installerpassword 4321
08 Userpassword 1234
09 Inputtime 00
10 Outputtime 00
11 Shutdownofthesector Able
12 Armsautomaticallybylackofmovement 00
13 Beepsofthesiren Able
14 Usevoicemodule Disabled
15 Remotecontrolregistration
16 Wirelesssensorsregistration
17 Deleteremotecontrolregisters
18
Deletewirelesssensorsregisters
19
Pulse/tonedialing(DTMF) Tone(DTMF)
20 Signalingfailwhilearmingsiren DIsabled
21 Panicaudíble/silence Audíble
22 Sirentime 05
23
NEW!
Lowbatterywarning(wirelesssensor) Able
24
NEW!
A/Dinput–armanddisarm(optionaldevice) Retention
25
NEW!
Callanswering–numberofrings 00
26
NEW!
ExternalLED/PGMoutputmode 01
27
NEW!
ExternaltimeLED/PGMoutputmode 001
28
NEW!
Timedsectors Alldisable
29
NEW!
Timefotautomaticrearm 00
30
NEW!
Selectingsmartsectors Alldisable
31
NEW!
Timeforsmartsectors 00
32
NEW!
Persistent/Interruptphonetrigger Interrupte
