Output specifications:
Updating time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 ms
Load stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 0.01% of span / 100 Ω
of span = of the selected range
Observed authority requirements:
EMC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2014/30/EU
EMC Emission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CISPR 22, Class B
LVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2014/35/EU
RoHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2011/65/EU
Approvals:
DNV-GL, Ships & Oshore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Standard for Certification No. 2.4
UL, Standard for Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UL 61010-1
Safe Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN 61140
EAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TR-CU 020/2011
I.S. / Ex approvals:
ATEX 2014/34/EU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . KEMA 10ATEX0147 X
IECEx . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . KEM 10.0068 X
c FM us. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FM17US0004X / FM17CA0003X
CCOE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P337347/1
Current output
Active Passive
Selectable NAMUR NE43
Max. load
Invert Range Limit Sensor error
Range
4...20 mA
3101

0/4...20 mA 0/3.8...20.5 mA 0/3.5/23 mA

≤ 600 Ω
3102

0/4...20 mA 0/3.8...20.5 mA 0/3.5/23 mA

≤ 600 Ω
3111

0/4...20 mA 0/3.8...20.5 mA 0/3.5/23 mA

≤ 600 Ω
3112

0/4...20 mA 0/3.8...20.5 mA 0/3.5/23 mA

≤ 600 Ω
3113

4...20 mA 0/3.8...20.5 mA 0/3.5/23 mA

≤ 600 Ω
3331
 
4...20 mA 3.8...20.5 mA 3.5 / 23 mA

(V
supply
-5.5)/0.023 [Ω]
3333
 
4...20 mA 3.8...20.5 mA 3.5 / 23 mA

(V
supply
-3.3)/0.023 [Ω]
3337
 
4...20 mA 3.8...20.5 mA 3.5 / 23 mA

(V
supply
-6.2)/0.023 [Ω]
Selectable voltage output
Low range High range
Min. load
Range Limit
Sensor
error
Range Limit
Sensor
error
3101, 3102,
3111, 3112
0/1...5 V 0/0.875...5.125 V 0/5.5 V 0/2...10 V 0/1.75...10.25 V 0/11 V 10 kΩ
