PR RACING SB401 - Page 17

BAG
B
A4
10
Rear Central Transmission
A5
M3X10mm
80000010
68480096
68480386(89mm)
79400066(9.8mm)
01480016
5x11x4mm Ball Bearing
68480066
66400786
10x15x4mm Ball Bearing
66400786
10x15x4mm Ball Bearing
M3X10mm
80000010
68480066
68480576(15T)
M4X3mm
86480016
68480336
66400776
5x13x4mm Ball Bearing
68480326
66401096
10X12.5X0.1
85440230
Please add it or not
according to the loose-tight.
10X12.5X0.1
85440230
Please add it or not
according to the loose-tight.
Saddle Battery
↙
Front
組裝時請注意齒輪方向
！
1
5x11x4mm Ball Bearing
1
5x13x4mm Ball Bearing
2
10x15x4mm Ball Bearing
M4X3mm Set Screw
1
M3X10 Button Head Hex Screw
6
Please notice the
direction of gear.
Rear


PR SB401
89mm
依據鬆緊，請加它或不加它。
依據鬆緊，請加它或不加它。
5X8X0.1
85440110
