PR RACING SB401 - Page 28

BAG
D
BAG
D
21
Steering

Body Mounts



mm
6.2~6.3
68480106
M3X8mm
80000010
M2.6X6mm
82000010
將伺服機電源線穿過整線夾,
避免伺服機電源線被中央傳動系統夾斷
M2.6X6mm Flat Head Hex Screw
3
M3X8mm Button Head Hex Screw
1
Servo power cord through the cable clips.
To avoid servo power cord pinched off mid
drivetrain system.
66400066
68480456(28mm)
