7 Operation
36
17.12.2 P7500i
1. According to the required voltage requirements, select the gear of
voltage change-over switch.
2. Turn the switch to “On” position.
3. Press and release the start switch button. The start switch will start the motor
for 5 seconds. When the engine starts successfully, the starter will stop
automatically. If the engine does not start successfully, wait at least 10
seconds before starting again.
NOTE: Is it also possible to start the engine with the recoil starter:
1. Turn the lock 90° anticlockwise and open right maintenance door. Pull
slowly on the recoil starter until it is engaged and then pull it briskly. Turn the
lock 90° clockwise and close right maintenance door.
7.13 Stopping the Engine
Before stopping the engine turn off and disconnect any electronic devices attached
to the generator.
Turn the Throttle switch “O”.
