8 Maintenance
44
d. Remove the battery band from the hook at the bottom of generator.
e. Remove the battery from the mounting box.
Install the battery (where available)
Battery terminals, wiring terminal and associated accessories containing lead and
lead compounds. Wash hands immediately after handling.
1. Put the battery in the mounting box.
2. Connect the positive (+) cable with the positive (+) terminal of the battery,
tighten the bolt and cover the rubber cap.
3. Connect the negative (-) cable with the negative (-) terminal of the battery and
tighten the installation bolt.
4. Install the battery band.
5. Reinstall battery maintenance cover and tighten the bolts. In the case that the
battery maintenance cover is not assembled, it is strictly prohibited to run the
generator, otherwise the performance of the generator and the engine will
become poor.
NOTE:
• Be sure the ESC is turned off while charging the battery.
