pratic LEVEL - Wall Mounting Systems; Wall Support

PAG. 13 Pergola LEVEL - manuale di uso e installazione Rev. 06/17
1P
LC2LC1
L
1cm
L
B - 16cm
LC1 LC2
==
B - 16cm
1cm
L
B - 16cm
MANUALE DI INSTALLAZIONE
INSTALLATION MANUAL
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
SCHEMA INTERASSI
INTERAXIS SCHEME
CONFIGURATION D’ENTRAXE
BEFESTIGUNGSABSTAND
L
LC1
LC2
LC3
B
C
> 5 cmB
√
Attacco a parete
Wall support
Support mural
Wandgestell
