PRECIOUS PLASTIC Extruder Pro - Page 5

5
1.3 Specifications
Weight 110 kg
Dimensions (l x w x h) 1105x670x1460mm
Voltage 400 V, 3 phase
Total power consumption 4,8 kW
Motor Power 3,0 kW
Heating power 1,8 kW
Required amperage 16 A
Screw speed @ 50hz 227 rpm
Pressure
Rated up to 200 bar
Input Thermoplastics
Rate troughput 15 kg/hr
Screw diameter 30 mm
L/d screw 20:1
Maximum temperature 350ºC
Temperature regulation Yes
Heater type Band heater
Number of operators 1
