Hold the
wrench by the
ratchet end in
your left hand
The lock lever
will spring
closed against
the adjustment
knob
Close lock
lever with
right index
finger
Use your
thumb to
open the lock
lever
The lock lever
will spring
open against
the handle
Use your right
hand to ad-
just torque
setting in the
window
Setting the
Precision Instruments
C-Line Click-Type
Torque Wrench
IN1248 9/07
