3
Ref. Qty. Description
5
6
7
8
9
10
11
12
13
14
15
16
17
1
2
2
4
2
4
1
1
8
1
1
2
2
1/2” x 2-1/4” Clevis Pin
3/8” x 2-1/4” Hex Head Bolt
3/8” x 1-1/2” Hex Head Bolt
3/8” x 1” Hex Head Bolt
3/16” Cotter Pin
5/8” Flat Washer
#14 Hitch Pin Clip
3/8” x 3/8” Spacer
3/8” Nylock Nut
1/2” x 2-1/2” Hex Head Bolt*
1/2’ Nylock Nut*
Clevis Plate
1” Handle Grip*
Having Problems?
Installation Questions?
Missing Parts?
Replacement Parts?
Don’t go back to the store!
Let us help you!
Please call our helpful Customer Service Department
Toll-Free at (800) 225-5891 We will be happy to
assist you.
STOP
* Denote parts used only in PLR1824 & PLR1836T
5
Parts Used During Assembly
Shown Full Size
Not Shown Full Size
6
7
8
9
10
12
11
13
14*
15*
16
17*
To Next Page
