Rev 8/2014
PrecisionTemp, Inc • 11 Sunnybrook Drive • Cincinnati, Ohio, 45237 • 1-800-934-9690 •
fax 513-641-0733 9
Service Time Replacement Guide for PT-200
Part
Number Component Description
Diagnostic
Time Replace
Test
1019 Ignition Probe 0.3 0.2 0.1
1092 Modulating Valve 0.50 0.5 0.2
1119 3 Amp Circuit Breaker 0.20 0.2 ▬
1436 T-In Assy 0.20 0.2 0.1
1437 T-Out Assy 0.2 0.2 0.1
1463 Solenoid Valve NG Robertshaw 0.50 0.5 0.1
1496 Wire Harness 12v DC to Board 0.20 0.2 ▬
1613 24v DC Power Supply 0.30 0.3
▬
1615 Relay 12v DC Control 0.30 0.2 ▬
1616 Pressure Switch 0.30 0.2 0.2
1634 Pressure Reducing Valve ▬
Parts
Only ▬
1749 ECO 0.2 0.2 0.1
1752 Pressure Relief Valve ▬
Parts
Only ▬
1765 Ignition Wiring Harness 0.3 0.3 0.1
1826 Power Wire Harness /Cont Bd. 0.20 0.2 ▬
1854 T-Mid Assy 0.2 0.2 0.1
1875 Blower Assy 0.30 0.5 ▬
1896 Dual Temp Dig.Display 0.20 0.3 ▬
1897 12v DC Power Supply 0.2 0.3 ▬
1994 Heat Exchanger w/ass't parts ▬ ▬ ▬
2004 Switch on/off 0.20 0.1 ▬
2066 T-In Assy, temp display 0.2 0.2 ▬
2067 T-Out Assy, temp display 0.2 0.2 ▬
2354 Flowmeter Assy 0.30 0.3 ▬
2412 DSI Board 0.3 0.2 0.1
2416 Flow Meter Gaskets 0.20 0.3 ▬
1841 200 Control Bd. & Microprocessor 0.50 0.2 ▬
ACAL Automatic Calibration ▬ 0.5 ▬
